Parametric Sheet Metal Enclosure Automation Engine
Algorithmic 3D modeling and CNC DXF generation for customized electrical enclosures with dynamic cutout layouts.
Client: Enclosure Fabricator
Stack: SolidWorks API, VBA / C#, Sheet Metal +2
01 Challenge & Solution
1. Project Background
Custom electrical enclosures require precise hole cutouts, louvers, and DIN-rail mounting studs tailored to each client’s industrial electrical schematics.
Engineering Workflow
- Rules-Based Parameter Validation: Ingests electrical component lists and auto-computes optimal enclosure dimensions, thermal dissipation clearances, and bend radii.
- CNC Flat Pattern Generation: Outputs nested DXF files with automated bend lines, tool punch annotations, and grain orientation markers.
Visual Documentation
Project Gallery & Technical Visuals
High-precision 3D CAD renders, exploded assemblies, and fabrication documentation.
Technical Stack
Technologies, Tools & Frameworks
The specialized CAD platforms, automation scripts, and engineering tools employed.
SolidWorks API
VBA / C#
Sheet Metal
CNC DXF Export
K-Factor Optimization
