Enterprise Homelab Infrastructure & Cloud Edge Cluster

High-availability dual-node Proxmox VE hypervisor cluster, TrueNAS ZFS storage pool, Kubernetes orchestration, and Cloudflare edge tunnels.

Client: Personal Engineering Lab

Stack: Proxmox VE, Kubernetes (k3s), TrueNAS CORE +3

01 Challenge & Solution

1. Infrastructure Overview

A production-grade self-hosted DevOps lab environment designed for CI/CD runners, CAD batch compute nodes, object storage mirroring, and internal telemetry.

Technical Specifications

Compute: 2x AMD Ryzen 9 5900X (24 Cores / 48 Threads, 128GB ECC DDR4).
Storage: TrueNAS ZFS Z2 pool with 6x 12TB Enterprise SAS drives and NVMe L2ARC caching.
Networking: 10GbE SFP+ backbone with VLAN segmentation, pfSense firewall, and Cloudflare Zero Trust Tunnels.

Visual Documentation

Project Gallery & Technical Visuals

High-precision 3D CAD renders, exploded assemblies, and fabrication documentation.

Technical Stack

Technologies, Tools & Frameworks

The specialized CAD platforms, automation scripts, and engineering tools employed.

Proxmox VE

Kubernetes (k3s)

TrueNAS CORE

Cloudflare Tunnels

Docker

Grafana
