ISO 286-2 Tolerances for Holes and Shafts (Engineering Wall Chart)
High-resolution printable engineering wall chart covering fundamental deviations, IT grades (IT5 to IT11), and clearance/transition/interference fits.
GD&TISO StandardsMachiningTolerances
1 min read #GD&T#ISO Standards#Machining#Tolerances
ISO 286-2 Standard Fit Reference
This technical reference chart provides calculated tolerance limits for standard metric diameters from 1mm to 500mm:
- Clearance Fits: H7/g6, H7/h6, H8/f7, H8/e8
- Transition Fits: H7/k6, H7/m6, H7/n6
- Interference Fits: H7/p6, H7/r6, H7/s6
